My new scarf

In March 2020, just before COVID, he and I went to New York, sharing one carry-on bag (we travel light and fast). I’ve just checked my calendar to see how long we were there; in my memory it’s both forever and no time at all, but in fact it was an intense fun- and food-filled ten days. One was spent walking from our hotel in The Bowery to see Japanese textiles at Sri Threads, with lunch at a Polish restaurant that we still remember for fabulous food and our first Żywiec beer. I’d been following Stephen @Sri for years and his collection did not disappoint. The wisteria bast fabric, the museum-grade boro were beyond my means, but I brought home some wonderful and meaningful textiles including a worn but very beautiful sakiori obi. My plan was to cut it and make a series of small bags to showcase the fabric, but I found I just could not put the scissors to it. Not just because it’s a wonderful long beautiful thing, but because it was still a thing. It wasn’t so worn that it couldn’t be used in its entirety. And also because this was made by someone’s hands as that single thing. Someone dismantled the garments for fabric, cut strips, wound that warp, warped the loom, chose or simply took strips to weave as weft. There is no repeat. When I’ve woven random yarns like this I’d sometimes pause to admire some unexpectedly beautiful progression: did the person who wove this pause, and for which colours?

Packing my workroom for the move made clear to me how many unfinished projects require my attention. They weigh me down: i am finishing some and disposing of others. This beautiful thing could become a striking if somewhat long scarf to be loved and admired into the future if I repaired it to withstand light use. 

Obi?
An obi is a Japanese belt, traditionally a woven fabric but modern obi may be made of many materials. There are obi (several types) for women and for men; men’s obi are narrower, longer (men wrap three times around the waist, women two) and usually more sombre in colour than those worn by women.

Left, an 1890s photo of one woman tying a complex obi knot. Right, a modern man’s kaku obi (my reading suggests this would be more stylish with the knot worn a little to the left).

My obi is roughly 15cm/6″ wide and 3m/9.8′ long, the standard dimensions of a hanhaba or ‘half width’ everyday casual woman’s obi. If that’s what it is, given the age of the obi, it would have been wound unfolded twice around the waist then tied with a simple over-and-under knot.

Sakiori: an examplar of mottanai
Meaning something like ‘what a waste/shame’ in the sense of ‘don’t be wasteful’, mottanai is a Japanese philosophy born of poverty and respect for crafts and materials. There is no need (it is inappropriate and disrespectful) to buy new if the old can be repaired, re-used or recycled. Garments can be repaired and remade for further use and when repair is not possible the fabric itself still has value: it can be cut into strips for use as weft in a new woven fabric (sakiori) or even unravelled, sound weft thread by weft thread to be re-used as weft in a new zanshi (‘leftover thread’) fabric.

A burn test suggests the black warp is silk; it burned briefly and sullenly with the scent of burnt hair. The wefts are strips of at least 23 different silks ranging in colour from palest grey to various blacks with grey patterning. The narrowest weft stripe is 3 passes of a pale grey similar to that in the middle of the image above (but the strip is thinner); the widest is 26 passes of a blue and white silk similar to that near the bottom of the image. A true vivid deep purple is the least common colour, only 5 stripes. Most of the silks are rich shades of brown combined with greys and blacks.

Think for a minute about the possible age of these fabrics. Folk textiles are difficult to date, but sakiori fabric is no longer widely woven. The obi is worn beyond use, from long use. As were, probably, the garments dismantled and woven into it. If it was woven at the beginning of the 20th century, the fabrics may date from the 19th century. All those years, all those people making and wearing the garments.

The photo above shows some of the damage. The worst is the selvedges, in many areas eroded to nothing but worn ends of weft strips. Within the body of the obi the warp is worn or has disappeared entirely over bumps in the weft, creating weak points where the weft strips part. There is no central wear line, so it was not folded in use. At one end there are large open holes several cm wide. It might be that this is the result of wear due to knotting, or it could simply be moth or beetle damage.

I tried various blanket and buttonhole stitches on the damaged selvedges, then unpicked most of them leaving only two small areas to remind me that they don’t work, the pattern and texture is inappropriate. In the end I repaired the edges as I did the weak areas in the fabric, re-weaving the warp over-and-under. I worked as close to the edge of the obi as I dared before locking every second or third stitch back into previous stitches. Where the weft fabrics were too badly damaged to hold the new warp I stitched patches of vintage silk, indigo blue or zanshi multicolour and gold. I used 60/2 grey silk where I did not want my stitching to show and Sajou Fil au Chinois where I wanted the repairs to glow like kintsugi gold.

I like the end result enough that I thought of signing it but that seems disrespectful to the person or people who made the obi. Instead I stitched a yatagarasu, the three-legged lucky crow-guide that may be sent by the gods, on the largest patch. Everyone can do with luck and guidance these days.

This particular Triumph of Perseverance Over Stupidity is complete.

offtheloom

The cotton warp I described in Slow Cloth, well-travelled is woven, off the loom, finished. 6.18m/6.75yds of fabric c. 9″/23mm wide. Cotton singles warp, silk and cotton singles weft, all dyed in a (fructose, from memory) indigo vat. Note that the warp stripes are unplanned and result from differential dyeing by the different colours and types of cotton.

A couple of people have asked for more technical information about the yarn (wpi, tpi). Remember that this was random spinning over the last 5 years or more, not directed spinning for the project. Cottons include pima, supima, organic green and brown, spun from punis, top and directly from the seeds, on tahklis, charkha, Majacraft quill and lace flyer. All were spun clockwise, or z. The yarn(s) vary widely in grist. In the photo below of remnants of the sized warp the 1/2″ wide sample is wrapping at roughly 52-56wpi. In the 1/8″ sample the yarn is wrapping at over 70wpi. (The greenish colour is indigo over natural brown, which together with its thinness tells me this was probably tahkli spun from seeds on my lap in front of the tv. Why weave your handspun? For the memories.)

WPI

Twist per inch is also variable. It is difficult to see the twist in the sized yarn, but examining unsized yarn in the weft bag – the warp was selected randomly from the skeins of dyed yarn, so both are equally variable – with a magnifier I eyeballed twist from roughly 45° to 55–60°, assuming 90° is perpendicular to the length of yarn. So it’s reasonably high twist… and that’s AFTER boiling. The yarn was probably fractionally thicker before boiling, so add something to those twist angles for twist on the singles as they came off the bobbin/shaft. Basically, sample. That’s what this fabric is, a jacket-length sample.

I like it.

washed,ironed

That’s the fabric finished to my current satisfaction. An overnight soak followed by wool/handwash cycle did not remove the gelatine size, so I soaked this in a bucket of the hottest water from the tap plus a couple of kettles of boiling water, washed on permanent press ‘warm’, then ironed on hottest cotton setting. It’s shrunk about 10% in width. I like it a lot. Despite the cursing and frustration, I also appreciate the lessons it has taught me. Some are unlikely to be needed again, such as: Do not expect a warp on the loom to make an international move without shifting somewhat. Others may be useful time and again.

My handspun cotton weaves well, but beware of slubs.
Some of my earliest and most unevenly spun cotton singles are in this warp. Only the very thinnest singles snapped under the quite high weaving tension, and by ‘very thinnest’ I mean places where uneven singles were thinner than fine sewing thread so I confess I’m feeling smug and planning a super-thin cotton fabric. But thick slubs are as bad or even worse than thin spots: the slubs hold more size, so are stiffer and fail to bend around the weft. They stuck up out of the fabric a bit after weaving and some are still visible after finishing. I can live with this.

slub

Most of my stupid mistakes occurred during the weaving; I’m even more proud of my spinning because the singles stood up to such mistreatment.

Wind sized yarns from the skeins onto bobbins before winding the warp.
See the underline? That means this one’s particularly important. Because winding the warp from a skein held on a flexing umbrella swift with occasional pauses to break the yarn free from places where the size has stuck threads together is not exactly conducive to even warp tension, is it?

I am rubbish at winding warps.
Perhaps fractionally less rubbish now because I’ve wound a few since this one, but still. This warp was wound one thread at a time from two different umbrella swifts over the course of three days. Should I be surprised that I had to hang a chiming array of weights from slack threads? No, I should not.

Thoroughly set the weft twist before weaving.
Or be prepared to guard against pigtails forming when you slacken tension to beat it into place. I am told that many traditionally-spun and woven cotton fabrics from South America have these pigtails, so it’s authentic, but still. I prefer my fabric without.

Be open-minded about lease sticks in or out while weaving.
The lease sticks were useful for this warp, seeming to help even out the tension. But on earlier fuzzy warps (cashmere and fine merino handspun lace) the lease sticks seemed to raise the fuzz, encouraging the the ends to stick together.

But enough criticism.

ThreeFabrics

The fabric is slightly stiff even after the size has been washed out, reminiscent of the stiffness of new denim in the days before lycra. Not as stiff as those old new jeans – it’s a much thinner fabric – but similar. I’m guessing I’ve achieved my goal of spinning and weaving a cloth that will soften with wear like the denim of yore.

The warp was threaded for point twill; the fabric shows the three different weaves. To right plainweave/tabby; centre first twill (Strickler p.28 #94, Point twill from A German Weaver’s Pattern Book 1784–1810); left 8-shaft diamond twill. (The red line marks the point where I changed the tie-up from first to second twill.)  The width of the fabric decreased between patterns as the interlacement changed; the first twill (#94) is narrower than plainweave as the twill pattern packs threads more densely. The second twill, 8-shaft diamond, has no band of plainweave so packs even more tightly for a fabric slightly narrower than the first twill. The silk weft and denser packing of the twills makes both heavier fabrics, but not dangerously dissimilar to the plainweave with cotton weft.

The plainweave shows the warp striping most clearly and, like the wool singles fabrics I have woven, it is a little more elastic than a fabric woven from plied yarn. It’s heavy shirting in weight, noticeably lighter in the hand than either twill. To be expected, but it’s interesting to have it confirmed.plainweave

The patterning of twill #94 is less obvious in the fabric than I’d hoped. It’s there if you look closely, though.#94

Once again 8-shaft diamond twill is just right, at least as far as I’m concerned. The fabric has the hand of lightweight denim. It looks good with the silk weft.
diamond

But I think it looks even better with the slightly paler blue cotton I used when I finished the silk (or at least couldn’t find any more).
diamondcotton
The pale blue fades in and out of the warp cottons, the diamonds seeming to shimmer in the fabric. It’s country cloth, but it’s interesting. I should play with the effect, I like it so much. I wish I had more than 24cm.

So. What am I going to do with it? Being a process rather than project person I’d really love to put it away and make the next fabric, but that defeats the purpose somewhat. There is more to be learned from this sample: I need to know how it wears. I could just bundle it into a bag and handle it until it softens but really, it’s fabric. It should be a garment. A sample can be a jacket or a shirt, and I think that’s what this will be once I overcome my fear of making garments. Why spin and weave? To make a garment from cloth you cannot buy, where one warp makes three different patterns for different parts of the garment. Eventually!

Slow Cloth update: The Triumph of Persistence Over Stupidity

Consider this the digital equivalent of a huge sigh of relief.

As you can see, the Slow Indigo Cotton warp has a new less flattering but educational name. I’ll explain that once it’s off the loom and finished, at which point I daresay more of my stupidity and – to be fair – ignorance will be revealed. In the interim, I am pleased to say my plan for it is working and we’re into the endgame.

fullsizeoutput_380

Why weave by hand? Why not just buy fabric?

Because as a hand weaver, even a new and somewhat ignorant hand weaver, I can make fabric you can’t buy. I threaded this warp for an 8-shaft point twill, then wove 3.5m of plain weave with cotton weft to get to this point, where I switch to a twill tie-up and indigo-dyed handspun silk weft. The patterned cloth will be used to accent parts of the garment made from the plain cloth. I don’t know what it will look like yet, that will depend on what the cloth looks and feels like after finishing. I’ve planned and am hoping for a hard-wearing heavy shirting/light jacket fabric, stiff to start with but softening with wear. Fingers crossed!*

* When I’m not using them to throw the shuttle.

Slow cloth, well-travelled

My last post was written in May 2017 sitting at the desk my husband made for me, beside a window looking out on my English garden in an English village (true, but much less quaint than it sounds).

This post is written from what was our kitchen table, repurposed as my temporary work desk, with a window looking out on our new garden on Vancouver Island, Canada. I’ve come home. Almost. ‘Home’ would be Alberta in the 1970s, but southern Vancouver Island is nonetheless a good place to be. Immigrants ourselves, in the summer of 2017 we fled Brexit Britain for our native land, arriving in time to celebrate Canada’s 150th. For nearly 12 months the logistics of our move – selling the house, selling everything we didn’t think worth shipping, packing – and fulfilling my spinning teaching commitments consumed all my time and energy. Only now am I starting to think and plan future textile projects.

But first I have to finish what I started.

Stephenie Gaustad taught me to spin cotton at SOAR in 2009. I fell in love with the banjo charkha, but couldn’t hide it under my sweater to bring it home when class finished so I’ve had to settle for tahklis and bead-whorl spindles, a T-frame charkha, Majacraft Suzie Pro and a Rose. I spun cotton on all of them and my bag of singles skeins grew larger. I learned to weave. One of my first projects on the Baby Wolf was a tiny warp of handspun cotton singles. Success! (Mostly.) Now I knew why I hadn’t plied those skeins, but increasingly I wondered what sort of cloth they’d make. In fact I needed to know, because there’s no point in spinning more cotton for weaving if what I’m spinning won’t make a cloth I like. There was only one way to find out: weave what I had. I’d spun natural shades of cotton from cream, brown and green through to white. I put the whole lot through an indigo vat because I like blue. Plus some handspun silk singles because I had A Plan.

IMG_3109Indigo-dyed handspun cotton singles drying on the rosemary bush by the kitchen door. I miss that bush, and our North Ronaldsay sky-blue doors.

IMG_3111I had to finish drying the yarns on the radiator. Hmm. Clearly I dyed silk fibre, too. I wonder where that is? In one of the many boxes, of course.

IMG_3117The gelatin-sized yarns drying under light tension – those water bottles are not full! – suspended between the hoe and an old rake handle wrapped in clingfilm aka Saran wrap on the clothes tree. The old grey lunchbag contains clothes pegs.

The shorter skeins were hard-spun ( which means with lots of twist) on the tahkli; I put them to one side for use as sewing thread, calculated the remaining yardage and wound a warp. I estimated the set, the number of warp threads per inch from wpi, wraps per inch around a ruler, then beamed the warp and wove a bit.

A digression dealing with the value of my time and the lifespan of the cloth I want to make. Modern fabric is generally soft when you buy it, even before you use it. The yarns are relatively softly spun, the cloth is woven and finished to be soft. Soft yarn, soft cloth doesn’t stand up to wear. It stretches out of shape, fibres pill and pull out of the fabric. This suits our ‘I want it soft and I want it right now’ society and, even better, it makes money for the manufacturers of clothing that will wear out as well as go out of style in under a year. But I invested a lot of time in spinning the yarn for this. Pre-Industrial fabrics, handspun, handwoven and hand-sewn, expensive as reflected the time needed to make them, wore well enough that clothing and bedlinens are often included in wills. I want to make cloth that reflects the time it took to make, that serves me well for years, that wears well. It will be hard to the touch to begin with but soften with wear and age.

Deciding the set for handspun yarn is tricky unless you’ve spun yarn to replicate an existing fabric. Standard set charts may be misleading: you can set your yarn like a commercial yarn of similar grist, but if your handspun is a different fibre and/or more or less tightly twisted, it will behave differently from the commercial yarn when finished and you’ll end up with a different fabric. With handspun I start with wpi, tweak it according to what I think of the cloth on the loom, and keep samples for future reference.

I looked at what I’d woven at 40epi, decided it was sleazy, unwove the inch, re-sleyed, wove a bit. Looked at it, decided it was still too open, unwove the inch, re-sleyed, wove a bit. I may have done this a third time, but kindly time blurs painful memories. Eventually what I’d woven looked enough like the fabric I wanted, warp-dominant to emphasize the stripes, that I cut the woven strip off to see what it looked like after hand washing. The small block shows the set and picks per inch off the loom, the long strip has been washed. The brown and tan cottons have dyed greenish. Other stripes are variations in the cream and white cottons, perhaps the result of variations in twist or in the fibres themselves.

IMG_3578

That doesn’t show how washing affected the density although you can clearly see the that the warp has shrunk (the unwashed sample is taller). With the light behind it the overall shrinkage is more obvious, as are the reed marks, the open lines between the groups of ends (threads) that run in each dent of the reed. They’re almost inevitable given that I had no finer reed, but I’m trying to think of them as a design feature – they can be – and they’re less obvious in the washed strip anyway. Notice also that the warp threads have moved in the washed fabric: hot water revives the twist, but the weave structure locks the threads into position. I may see some tracking in the final fabric.


On balance that sample was acceptable. It’s 50 epi set in an 8-shaft twill currently woven plain weave according to my Plan. It’s 9″ wide on the loom and I think the warp is about 5m long (the one thing I forgot to write in the book). The washed sample shrank roughly 10% in both warp and weft.

I’d hoped to have this woven and off the loom before we left the UK, but I had no time. When the movers arrived I simply folded the Baby Wolf, roughly wrapped paper around the beams, and left them to pack it. Unlike our more fragile ceramics (yes, I am bitter), the loom arrived undamaged. The warp had shifted somewhat, but less than I feared, and as it wasn’t well-wound or beamed in the first place that’s the lesser problem. I’m getting better at warping, but I need a lot of practice.

IMG_4622I have started weaving some fine yarns with the lease sticks in place. Like back-to-front or front-to-back warping, lease sticks in or out is something weavers seem to choose as habit early in their careers. I didn’t like the lease sticks in when weaving thicker, fuzzy yarns: my impression was that the sticks were encouraging fuzziness and binding of threads in the warp. But feeding firmly sized, finer yarns through the even tension of the lease sticks seems to correct some of my warping issues.


The colour is more accurate above. Below, a closer view of the fabric on the loom. The slightly more open weave below my thumb is where I started weaving again in Canada. Below that you can see some annoying imperfections, places where slightly thicker areas of the sized warp threads are stiffer and refuse to conform around the weft when beaten. They become much less obvious after washing and one could argue imperfections are part of the charm of khadi fabric, handspun and handwoven, but I’d prefer perfection. I see no reason to pursue anything less. To me the imperfections in this are a reminder that some of this is my earliest cotton spinning and weaving, because they’re less obvious now after I greatly increased the tension on the warp to pull them straight.


At any rate my handspun singles stand up to the test. They are weavable, and they are teaching me more about weaving. Time to start spinning more cotton!
